BF series
Paddle controllers
SPECIFICATIONS
MECHANICAL
Materials Employed
Weight
Mechanical Operating Angle
Max Load to Mechanism
–
–
–
–
Polyetherimide, Polycarbonate, Stainless Steel
50g
+/- 25 Degrees
Vertical: IK08 (BSEN62262:2002)
Horizontal: 75N (16.86lbf)
ELECTRICAL
A
Gain (Output Voltage Span)
Output at Center
Power Supply
Switch Outputs
Sensor Type
Current Consumption
Loads
–
–
–
–
–
–
–
+/-10% x V to +/-50% x V
V/2 +/- (5% x Gain)
5V +/-0.5V Transient free
Open Drain, pulled high within control via 1K5 to 5V,
and smoothed to 0V with 100nF
Hall effect
<20mA
Minimum 10K, preferred 100K+
ENVIRONMENTAL
Storage
Operating Temperature
Seal Above Panel
EMC Emissions
Life Cycles
ESD
EMC Immunity
Vibration
–
–
–
–
–
–
–
–
-40°C to 70°C (-40°F to 158°F)
-25°C to 70°C (-13°F to 158°F)
IP67 (Gasket fitted as standard)
Complies with EN 61000-6-3:2001 CISPR 22:2005 Class
B 30MHz - 11GHz
5 million cycles sprung version only. Detents rated to
2 million cycles
Complies with EN61000-4-2 (extended)
+/-8KV (20 contacts) & +/-15KV (20 air discharges)
100V/m, 80MHz-2.7GHz, 1KHz 80% sine wave
modulation, EN 61000-4-3 (extended)
100Hz - 200Hz @ 0.13g2/Hz, total 3.6gRMS (1 Hour in
each of the three mutually perpendicular axes)
All parameters shown are based on a standard configuration and are provided for guidance only.
Please refer to Apem for assistance on how to achieve the best performance from your chosen configuration.
Note: The company reserves the right to change specifications without notice.
